Workshop Air Cooling Giant Factory Ceiling Fan / Industrial Fans

Product Details

Payment & Shipping Terms

Get Best Price
Contact Now
Specifications
Highlight:

Air Cooling Giant Factory Ceiling Fan

,

Workshop Giant Factory Ceiling Fan

,

Workshop HVLS Industrial Fans

Specification:
Diameter Size From 7.3 Meter
Trademark:
DS
Origin:
China
HS Code:
8414591000
Material:
Aluminum Fan
Type:
Centrifugal Fan
Electric Current Type:
AC
Mounting:
Ceiling Fan
Certification:
RoHS, ISO, CE
Transport Package:
Wooden Package
Customization:
Available | Customized Request
Specification:
Diameter Size From 7.3 Meter
Trademark:
DS
Origin:
China
HS Code:
8414591000
Material:
Aluminum Fan
Type:
Centrifugal Fan
Electric Current Type:
AC
Mounting:
Ceiling Fan
Certification:
RoHS, ISO, CE
Transport Package:
Wooden Package
Customization:
Available | Customized Request
Description
Workshop Air Cooling Giant Factory Ceiling Fan / Industrial Fans

Workshop Air Cooling Giant Factory Ceiling Fan/Industrial Fans

Basic Info.

Specification
diameter size from 7.3 meter
Trademark
DS
Origin
China
HS Code
8414591000

Product Description

HVLS INDUSTRIAL CEILING FANS


The wind blown from HVLS industrial ceiling fan feels like natural breeze system,the wind speed is just the best cool feeling of human skin. Personnel can feel the temperature difference 5-8 degree, provide personnel a suitable working environment in hot summer,improving the production efficiency.

Workshop Air Cooling Giant Factory Ceiling Fan/Industrial Fans

Function of the fan:

ventilation The fan improve air exchange in an entire space, it's perfect streamlined design can produces 2-3m/s speed three-dimensional wind, and makes personnel feel like the natural breeze system.It promotes the dispersion of smoke, moisture, carbon dioxide and poor air with high specific gravity.So as to improve the quality of working area, create healthy, dry and safe working environment, improve working efficiency.

convenience It is convenience to be operated, control system adopts the latest poleless frequency converter control system.besides of convenience operation, the humanized operation interface also allows you enjoy the beauty of electronic and mechanic achieve the life.

Dehumidification Because it can produce large air volume, effectively promote air circulation, so that the moisture is well dispersed, greatly reducing the probability of problems such as bedbugs, fungi and so on.
4)beautiful and durable
After complex surface treatment,the product can avoid the pain of period cleaning,the cost-performance ratio is the highest,the life of each fan can reach more than10 years.


energy saving The rated power of the motor on the fan is 1.5KW,each fan can cover 1000 square meter working area,8 hours per day, is just 10 degree power energy consumption,compared to typical small fans and high power consumption air condition, our industrial ceiling fan can be called model of energy saving, and greatly reduce your operation cost.



DAISEN PRODUCT CATALOG AS BELOW:

Series Model Numbers of the blades Voltage Power Diameter Drive mode Max speed Max air volume Max coverage area(m²) Fit for installation height(m) Noise level Net weight
DS
(Gearbox motor)
DS-7.3 6 220V/380V 1.5KW 7.3M (24FT) Gearbox motor drive 50RPM 888000m3/h 1200 7~18 60db 156kg
DS-6.7 6 220V/380V 1.5KW 6.7M (22FT) Gearbox motor drive 52RPM 822000m3/h 1000 6~15 60db 152kg
DS-6.1 6 220V/380V 1.5KW 6.1M (20FT) Gearbox motor drive 55RPM 774000m3/h 800 6~13 60db 147kg
DS-5.5 6 220V/380V 1.5KW 5.5M (18FT) Gearbox motor drive 60RPM 732000m3/h 600 5~11 60db 143kg
DS-5.0 6 220V/380V 1.5KW 5.0M (16FT) Gearbox motor drive 65RPM 690000m3/h 450 5~9 60db 140kg
DX
(PMSM motor)
DX-7.3 6 220V 1.5KW 7.3M (24FT)  brushless direct drive 50RPM 888000m3/h 1200 7~18 38db 106kg
DX-6.7 6 220V 1.2KW 6.7M (22FT)  brushless direct drive 55RPM 822000m3/h 1000 6~15 38db 100kg
DX-6.1 6 220V 1.0KW 6.1M (20FT)  brushless direct drive 60RPM 774000m3/h 800 6~13 38db 94kg
DX-5.5 6 220V 0.75KW 5.5M (18FT)  brushless direct drive 65RPM 732000m3/h 600 5~11 38db 72kg
DX-5.0 6 220V 0.7KW 5.0M (16FT)  brushless direct drive 68RPM 690000m3/h 450 5~9 38db 68kg
DX-4.2 5 220V 0.6KW 4.2M (14FT)  brushless direct drive 75RPM 636000m3/h 300 4~7 38db 64kg
DX-3.6 5 220V 0.3KW 3.6M (12FT)  brushless direct drive 90RPM 393600m3/h 250 4~6 45db 42kg
DX-3.0 5 220V 0.2KW 3.0M (10FT)  brushless direct drive 100RPM 331800m3/h 200 4~5 45db 38kg
DX-2.4 5 220V 0.15KW 2.4M (8FT)  brushless direct drive 100RPM 273000m3/h 200 4~5 45db 34kg


Key component configuration

★ drive device
• DX series fan adopts Taiwan/German gearbox motor
• DX series adopts the industry's first non carbon brush, large torque, DC drive motor, replacing the traditional motor speed reducer, realizing high integration, improving reliability and transmission efficiency

★ control device
• DS series fan adopts Taiwan / Germany brand inverter stepless speed change (optional explosion-proof controller) to configure circuit breaker overcurrent overload protection, cooling fan and other components
• DX series fans adopt a special brush free controller

★ fan blade
• The material of the fan blades adopt magnesium aluminum alloy T6 treatment, corrosion resistance, high strength, high toughness
• Advanced fluid simulation software CFD simulation and wind tunnel test, in line with aerodynamic anti fatigue;
• With the function of delay start, the load and impact of the motor are greatly reduced, and the service life is longer

★ Structure components
•  The structural parts are formed by Q235B laser, bending the stiffener structure, and the thickest part is 8mm.
• Alloy steel high strength bolts and anti-skid nuts are used for the bolts.
• Steel wire rope and turnbuckle tension structure to stabilize the fan against falling
• The integrated chassis can prevent the risk of fracture, the coupling anti falling structure can avoid screw defects, the chassis can be dropped, the hole arrangement design of plywood structure can prevent sliding, the adjustable structure is suitable for any installation conditions, and the arc-shaped adjustable waist hole can be adjusted to ensure the plane level of blade chassis



Workshop Air Cooling Giant Factory Ceiling Fan/Industrial FansWorkshop Air Cooling Giant Factory Ceiling Fan/Industrial Fans


Comparison of three refrigeration methods in 1000 square meter plant

Refrigeration mode Quantity Power/unit Tall power General comparison
Central air conditioner 1 80KW 80KW The walls and doors and windows of the plant are required to be insulated. The cost of one-time investment of the equipment is high, and the maintenance cost of replacing the filter element and adding refrigerant is high
Traditional industrial fan 40 0.3KW 12KW The installation of traditional wall fans is limited by walls and columns. The power lines of floor fans are scattered, which has potential safety hazards. It is not safe for the hair of staff members to be mixed into the fan blades, which occupies a small space and covers a short service life
7.3M HLVS industrial ceiling fan 1 1.5KW 1.5KW Large coverage area, long service life, low maintenance cost, installation does not occupy the workshop space, safety and environmental protection

Workshop Air Cooling Giant Factory Ceiling Fan/Industrial Fans
Workshop Air Cooling Giant Factory Ceiling Fan/Industrial Fans
Workshop Air Cooling Giant Factory Ceiling Fan/Industrial Fans



The energy consumption of large industrial ceiling fan is about 1 / 50 of that of central air conditioner and 1 / 10 of that of traditional industrial wall fan
