Multifunctional Industrial Large Ceiling Fan For Every Place Ventilation Equipment

Place of Origin Chengdu,China
Brand Name DAISEN
Certification RoHS, ISO, UL, CE, SGS
Model Number DS/DX
Minimum Order Quantity 1
Packaging Details wooden
Payment Terms L/C, T/T, Money Gram

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Specification Diameter 7.3 Meter Origin China
HS Code 8414591000 Port Shenzhen, China
Transport Package Wooden Material Aluminum Fan
Blade Material Aluminum Type Exhaust Fan
Electric Current Type AC Mounting Ceiling Fan
Certification RoHS, ISO, UL, CE, SGS
High Light

Multifunctional Industrial Large Ceiling Fan

,

7.3 Meter Large Ceiling Fan

,

Industrial Ventilation Giant Ceiling Fans

Leave a Message
Product Description

PMSM Motor Ceiling FAN

Multifunctional Industrial Large Ceiling Fan For Every Place Ventilation Equipment

The fan can push a large amount of airflow to the ground,forming a certain height of airflow layer on the ground to move horizontally,thus promoting the overall air circulation. The maximun diameter of large industrial fans can reach 7.3 meters,and the streamlined fan blades manufactured by aerodynamic principles and advanced technology can drive a large amount of air with only low power,and generate a large area of natural breeze system,which plays a role in ventilation. Dual function of cooling. Compared with traditinal HVAC and small-speed fans,it has unparalleled application advantages and is a perfect solution for ventilation and cooling in tall spaces.


Technical Parameters
Model Fan diameter Motor power Max speed Rated voltage Air volume Max coverage Weight Noise
DX-7.3 7.3M(24FT) 1.3KW 55rmp 220V/380V 14800M3/min 1200m2 106KG ≤60db
DX-6.7 6.7M(22FT) 1.3KW 58rmp 220V/380V 13700M3/min 1000m2 100KG ≤60db
DX-6.1 6.1M(20FT) 1.2KW 60rmp 220V/380V 12900M3/min 850m2 94KG ≤60db
DX-5.5 5.5(18FT) 0.75KW 65rmp 220V/380V 12200M3/min 600m2 72KG ≤60db

DX-4.9
4.9(16FT) 0.7KW 70rmp 220V/380V 11500M3/min 500m2 68KG ≤60db

DX-4.2
4.2(14FT) 0.5KW 75rmp 220V/380V 10600M3/min 400m2 64KG ≤60db

DX-3.6
3.6(12FT) 0.5KW 90rmp 220V/380V 6560M3/min 200m2 42KG ≤60db

DX-3.0
3.0(10FT) 0.3KW 100rmp 220V/380V 5530M3/min 120m2 38KG ≤60db

DX-2.4
2.4(08FT) 0.3KW 110rmp 220V/380V 4550M3/min 100m2 34KG ≤60db



DAISEN 'DX series',Industrial-grade safety structure, equipped with PMSM permanent magnet brushless synchronous motor, has the characteristics of safety, quietness, small size, maintenance-free, etc. It is a high-quality industrial high-quality large-scale ceiling fan.

Multifunctional Industrial Large Ceiling Fan For Every Place Ventilation Equipment 0
Multifunctional Industrial Large Ceiling Fan For Every Place Ventilation Equipment 1



* PMSM motor, small size, low noise, more suitable for low noise industrial space
* Permanent magnet synchronous motor, high torque, more energy saving, lifetime maintenance-free
* Multiple safety protection structural components to protect the overall safety of the fan
* Vector frequency conversion control, more stable and quiet start, various fault protection
* Air-driven variable-section streamlined fan blades, more balanced airflow

Features of Traditional HVLS Fans


Multifunctional Industrial Large Ceiling Fan For Every Place Ventilation Equipment 2
Universal joint:
The galvanized structure steel universal joint,can adjusts the horizontal and vertical direction to ensure the fan in vertical status. So that ensuring the balance of the fan in the process of rotation, and reducing the torsion transmission from the fan to the building.
coupling:
40Cr alloy coupling, CNC machining to ensure transmission stability
Other product accessories:
Select high strength screws greater than 8.8 grade according to different connecting parts of the fan,anti-loosing self-locking screws and and anti-slip nuts,together with anti-loosing thread glue,anti-falling connection rings,anti-falling connection parts of the blade.
Multifunctional Industrial Large Ceiling Fan For Every Place Ventilation Equipment 3
Installation kits:
Our company's unique design of row holes on the installation plate, can prevent the sliding of the installation plate, we also have installation kits for concrete and and circular tube structure as well as any other kinds of structure.
Multifunctional Industrial Large Ceiling Fan For Every Place Ventilation Equipment 4
Multifunctional Industrial Large Ceiling Fan For Every Place Ventilation Equipment 5
Steel rope:
8mm diameter steel rope wrapped with anti-rust plastic,reinforced rope clip,with anti-skip turnbuckle screw tension and adjust the horizon of the fan, prevents shaking of the fan, absorb the vibration energy.
blade:
The blade is made of aeronautic Al-mg alloy material that passed T6 heat treatment process,it has high strength,highdurability,the cross section of the blade is propeller streamlined to ensure the best energy efficiency ratio. It is easy to clean after surface grinding and extremely oxidation treatment. It has low wind resistance and high efficiency,There are two reinforced tendons and over-reinforcing structure.the thinnest part is 2mm,and the thickest part is 5mm,so as to avoid fatigue loss of the blade.
Multifunctional Industrial Large Ceiling Fan For Every Place Ventilation Equipment 6





Installation Diagram


* The height of the pharmaceutical workshop is more than 4 meters. It can be installed regardless of the structural steel structure, concrete structure, spherical grid structure or complex structure of the workshop; there are no special requirements for the installation site; it can be installed with or without traffic inside the workshop


* The safe installation space of the fan is greater than 80cm. The ideal height of the DS series installation space is between 4-20 meters.


Multifunctional Industrial Large Ceiling Fan For Every Place Ventilation Equipment 7
